WAVESHARE 128x128 General 1.5inch OLED Display Module 16 Gray Scale with SPI/I2C Interface

SKU: DIY1215
Sale Sold out Pre-order
Regular price R 449.00
Regular price Sale price R 449.00
Pay in 3, 6, or 12 monthly instalments with

Import Taxes & Duties Included

6-13 business days

In Stock CHN

Processing time: 1-3 days

Description

The WAVESHARE 128x128 General 1.5inch OLED Display Module is a display module designed for high-resolution output. It is suitable for applications requiring a compact display with a 128x128 resolution and 16 gray scale levels.

  • Display Type: OLED
  • Resolution: 128x128 pixels
  • Gray Scale: 16 levels
  • Display Color: White
  • Viewing Angle: >160°
  • Operating Voltage: 3.3V / 5V
  • Dimensions: 44.5 x 37 mm
  • Interface: SPI / I2C
  • Driver: SSD1327
  • Configuration: Configured via onboard resistor
  • Development Resources: Includes manual and examples for Raspberry Pi, Arduino, and STM32
